Cosen SH-520DM Semi-Automatic Double Mitre Bandsaw

$21,000.00

In stock

Achieve precise cuts with the Cosen SH-520DM Semi-Automatic Double Mitre Bandsaw. Designed for versatility and efficiency, this bandsaw handles a wide range of cutting tasks with ease.

  • Semi-Automatic
  • Double Mitre
  • Hydraulic Vice
  • 520mm cutting capacity



Brands:
SKU: 520mm Cutting Width

Cosen SH-520DM Semi-Automatic Double Mitre Bandsaw: Precision and Versatility Combined

The Cosen SH-520DM Semi-Automatic Double Mitre Bandsaw is engineered for exceptional performance and accuracy. Perfect for various cutting applications, this robust machine features a double mitre design, allowing for easy and precise angle cuts. The semi-automatic operation ensures consistent and efficient results, making it an invaluable asset for any workshop.

Key Features:

  • Saphead can mitre cut up to 60 degrees at both sides.
  • Easy to operate with a manual lock handle.
  • Rigid joint shaft and pivot system design make rotary cutting more precise.
  • Adjustable right guide arm for optimum cutting stability at bigger angles.
  • Blade tension adjustment device ensures the stability of saw band tension.
  • Material stays at the same place and does not rotate with saw bow or bed.
  • Full stroke hydraulic clamping vice.

Whether you need precise cuts for large projects or versatility for smaller tasks, the Cosen SH-520DM delivers unparalleled performance and reliability.

Video

Angle 0 degrees 45 Degrees 60 Degrees
Capacity Round 340 mm 320 mm 240 mm
Square 250 mm 250 mm 240 mm
Rectangle (HxW) 250 x 520 mm 250 x 520 mm 250 x 240 mm
Saw Blade Speed Step 60 Hz: 20, 34, 49, 76m/min
Size (LxWxT)  4242 x 34 x 1.1mm
Guide Interchangeable tungsten carbide
Cleaning Steel Wire Brush
Motor Output Saw Blade 3 HP (2.2 Kw)
Hydraulic 1/2 HP (0.37 kW)
Coolant Pump 1/8 HP (0.09 kW)
Tank Capacity Hydraulic 8 L
Coolant 40 L
Work Bed Height 800 mm
Weight Net 1015 KG
Gross 1200 KG
Floor Space ( Lx W x H) 1580 x 2375 x 1436 mm
