IMS Sheet Racks – Roll-Out Motorised

The IMS Electric / Motorised Drawer-Type Sheet Metal Shelving provides push-button access to sheet stock, reducing manual handling, improving safety, and speeding up workflow while keeping materials neatly organised.

The Electric / Motorised Drawer-Type Sheet Metal Shelving is a high-performance storage solution designed to simplify the handling of sheet stock. Using an electro-mechanical drive system, the shelving allows sheets to be retrieved or returned at the push of a button — reducing manual labour, improving operator safety, and streamlining workflow.

This intelligent storage system not only saves time but also maximises space and keeps materials neatly organised. Ideal for workshops, fabrication shops, and metal suppliers looking to boost efficiency and safety in their daily operations.

Key Advantages

  • Automated operation for easy sheet retrieval and return
  • Reduced manual handling, minimising operator strain
  • Faster material access and improved workflow efficiency
  • Organised storage that keeps sheet stock sorted and accessible
  • Built-in safety features to protect both operators and materials

Video

Model 3015 4015 4020 6020
Lod Single Layer 3T 3T 5T 6T
Plate Size 3000 x 1500 mm 4000 x 1500 mm 4000 x 2000 mm 6000 x 2000 mm
Number Of Layers (additional layers customisable) 5+1 5+1 5+1 5+1
Height Between Layers 220 mm 220 mm 220 mm
Width When Door Is Open 3515 mm 3515 mm 3515 mm 4015 mm
Dimensions (LxHxW) mm 3505x2280x2000 4505x2280x2000 4505x2280x2000 6505x2280x2000
Drawer Movement Method: Integrated pull-out type motorised / electric
